Advertising player
Overview
The Digital Advertising Player is a compact, high-performance device engineered to stream promotional content and messaging on display screens in retail outlets, hotels, airports, hospitals, banks, and more. Acting as the bridge between a Content Management System (CMS) and the screen, it reliably receives media files and plays them back in high resolution, 24 hours a day, 7 days a week.
2. Key Features
Feature | Added Value |
|---|---|
4 K / 60 fps playback | Ultra-sharp video and imagery with zero stutter, maximising audience engagement. |
24 / 7 duty cycle | Industrial-grade design tolerates harsh environments (0 – 45 °C, 0 – 80 % RH). |
Versatile connectivity | Wi-Fi 6, Gigabit Ethernet, and Bluetooth 5 for flexible networking and peripheral support. |
Expandable on-board storage | 64 GB eMMC plus M.2 SSD slot—store hundreds of clips locally. |
Hardened OS | Embedded Linux with Secure Boot and encrypted OTA updates for robust security. |
Cloud-based fleet management | Native integration with leading CMS solutions (Xibo, Scala, NoviSign) and an open API for custom workflows. |
Offline playback | Continues running pre-cached playlists during network outages. |
Smart scheduling | Time, location, and audience-based playlists to optimise campaign efficiency. |
Built-in analytics | Playback counters, fault alerts, and exportable reports ready for Power BI or CSV. |
3. Technical Specifications
Category | Details |
|---|---|
CPU | Quad-core Cortex-A55 @ 2.0 GHz |
Memory | 4 GB LPDDR4 |
Storage | 64 GB eMMC + M.2 NVMe slot (up to 2 TB) |
Outputs | 1 × HDMI 2.1 (4 K / 60 Hz), 1 × DisplayPort 1.4, 2 × USB 3.0, 1 × USB-C (PD), 1 × 3.5 mm audio |
Networking | 1 × Gigabit Ethernet (RJ-45), Wi-Fi 6 (2.4 / 5 GHz), Bluetooth 5.2 |
Dimensions / Weight | 140 × 90 × 20 mm |
Power | 12 V ⎓ 2 A (typical draw ≈ 9 W) |
Software Support | HTML5, H.265/H.264, VP9, JPEG/PNG/BMP, WebGL |
Certifications | CE, FCC, RoHS, Energy Star |
